High-Pressure Metal Baling • Optimized Logistics & Smelting Solutions
Our metal briquetting machine is essential for steel mills and recycling industries. It extrudes scrap steel, iron, copper, aluminum, and even dismantled car shells into high-density cuboids or cylinders. This process
significantly lowers transportation costs and simplifies furnace charging for smelting.
🕹️ Dual Control Modes
Equipped with both manual and PLC automatic control systems for maximum operational flexibility.
🏗️ Easy Installation
Hydraulic transmission with a compact structure. No foot screws required during installation.
📈 Wide Capacity Range
Pressure levels from 63 to 400 tons, with production efficiency up to 10 tons per hour.
| Model (Tons) | 100 Ton | 125 Ton | 135 Ton | 200 Ton |
|---|---|---|---|---|
| Total Power | 11 kW | 15 kW | 18.5 kW | 37 kW |
| Material Box Size | 1100x800x400 mm | 1200x800x550 mm | 1200x800x600 mm | 1600x1200x800 mm |
| Bale Size (cm) | 20×20*(40-60) | 30×30*(40-60) | 30×30*(40-60) | 45×45*(60-90) |
| Cycle Time | 80-100s | 80-100s | 80-120s | 100-140s |
| Dimensions (m) | 3.2×2.1×1.7 | 3.3×1.2×1.7 | 3.2×2.3×1.7 | 4.2×2.8×1.7 |
The machine utilizes the plastic deformation properties of metals under high pressure. When loose scrap is placed in the box, hydraulic cylinders exert sufficient external force to gather the material and produce permanent
deformation, creating a compact bundle. This improves labor efficiency and reduces labor intensity while maximizing storage compatibility.
Customizable Bale Specifications Available Upon Request.
